Description

Fresh %10 Neutral buffer formalin preparation from 37% Formaldehyde and dispensing device is a fully automatic device to prevent inhalation problem. Using  Formadose create big advantages compare to ready to use formalin. Laboratory can get  fresh %10 Neutral Buffer Formalin in cost effective way with ten times less storage area and transport issue. In addition to that the laboratories have ten times less plastic  waste container which  help to save the world

Ready to Use (10% Neutral Buffered Formalin) Manual Preparation (10% Neutral Bffered Formalin) Fully Automated Formalin Preparation & Dispensing Device (FormaDose)
User Safety
  • Minimum inhalation and contact with formaldehyde
  • Exposure to formaldehyde may occur intensively
  • Exposure limits (Short Term Exposure Limit and Permissible Exposure Limit) may be exceeded
  • Minimum inhalation and contact with formaldehyde for maximum safety
  • Obtaining formalin directly from the faucet at the grossing station
Consistency
  • Reduce potential error by having stable results with ready to use solution
  • Have potential risks of user errors regarding preparation of formalin
  •  Reduce potential error by having stable results with preparation of  correct concentration
Workload
  • Formalin containers must be transported to laboratory continuously
  • Every step must be performed by user
  • Eliminate manual process
  • Increase efficiency of your business

Cost

  • Comparatively the most expensive option
  • It is cheaper than ready to use form
  • Significantly reduce the cost by purchasing bulk packages of concentrated formaldehyde

Quality

  •  If formalin waits long time the formation of sediment welded from formalin residue may occur. Because of this it should be mixed before using
  •  If formalin waits long time the formation of sediment welded from formalin residue may occur. Because of this it should be mixed before using
  •  User always can prepare fresh solution
  • Automatic and manual mixing function prevents the formation of sediment welded from formalin residue

pH Monitoring

  • It is not necessary if formalin have good condition
  • User must have a pH meter
  • It must be measured the pH after preparation and before using
  • It is easy with integrated pH meter

Cost Effectıvıty

RTU Option Formadose Advantage of Formadose
The amount of formaldehyde for storage
1000 Liter
100 Liter
Significantly available more empty space. 90% advantage
The amount of formaldehyde should be transported from storage room to laboratory
1000 Liter
100 Liter
Less workload. 90% advantage
Total Cost of 10% NBF (it is calculated as the hospital will buy 10% NBF in 1 gallon boxes)
~8.000 USD
~2.400 USD
~5.600 USD

Features

Precise Dosing

  • High sensitive measurement method. – Pressure Transmitter
  • Additional measurement method using to check main method works well.
  • Wave breaker inside.
  • ±0.5% accuracy as ml

Less Workload

  • Not need to carry fresh formalin any place.
  • Possible to purchase big container: 25 liter 37% formaldehyde prepare 250 NBF.
  • Liquid buffer add automatically.

User Safety

  • Quick coupling connection to provide easy replacement.
  • Check valve in the line prevent any liquid separate during the replacement.
  • Main tank over flow sensor mechanical and electrical.
  • Fan and carbon filter inside.

Quality Control

  • Online pH follow up.

User Friendly

  • Not need any calibration, the device works with factory calibration.
  • Easy to use software, standard protocol available to prepare 10% NBF
  • Remote access is possible to easy and fast technical support.

Flexibility

  • If needed possible to prepare different concentration.

Optinal Accessories &Consumbles

  • Liquid buffer container
  • Spray gun
  • Solid salts as package for preparing 25 liter of Neutral Buffer Formalin.
  • 100 test kit for 10% formalin measurement.
  • Foot pedal for each grossing station

Technical Specifications

  • Tank Capacity: 100lt- The device not suitable to prepare less than 50 liter. If you are using less amount of formalin please contact with us for customise solution.
  • The device can feed multiple grossing stations.
  • Automatic mixing and possible to adjust the time to provide homogenous solution.
  • Mobile
  • Dimension :
  • Weight: 180kg
  • Electrical details:
    • Volts: 210 -230
    • kW: 1
    • Hz:50/60

FORMALDEHYDE MANAGAMENT SYSTEM

Pathology labs use formalin in fixation step  and volume of fixative should be 15- 20 times the volume of the specimen  and  formalin must be use as 10% neutral buffered formalin.



The most widely used formaldehyde-based fixative for routine histopathology. Many epitopes require antigen retrieval for successful IHC following its use. Most pathologists feel comfortable interpreting the morphology produced with this type of fixative. Cost effective fixation.

But on the other hand formaldehyde exposure  to formaldehyde has been shown to cause cancer according to International Agency for Research on Cancer (IARC) is part of the World Health Organization (WHO) and National Cancer Institute

In that point  formaldehyde management system which include three devices are essential for all pathology labs because its provides close system there is no inhalation from beginning to  end. Formalin also dangerous for environment for this reason it is also important the formalin waste treatment process.

  • Prepare %10 fresh NBF with FORMADOSE
  • Use at GWS series GROSSING STATION
  • Treat with NEUTRAFORM
